Equipment introduction and use
This line by for bottle - filling - prewhirl cover cover (robot) - screw cap, intelligent code can be labeled by the heat transfer unit in production line, is my company according to the requirement of the IVD industry research and design of intelligent to meet customer production requirements. Filling system adopts the trace line pump filling, easy to adjust the filling quantity and sanitary cleaning, filling accuracy is high, the filling without dripping phenomenon, filling quantity can adjust the touch screen. Prewhirl covered with robot take cover, screw cap adopt servo motor, guarantee the qualified rate of high production efficiency. The machine adopts PLC programmable controller to the automatic control of related functions, such as: no bottle no filling, do not cover, no cover or eliminate alarm function, the use of simple operation, easy to adjust. Equipment is mainly used for clinical biochemical reagents, immune diagnostic reagents, molecular diagnostic reagents, microbial diagnostic reagents, diagnostic reagents, urine clotting diagnostic reagents, hematology diagnostic reagents, flow cytometry diagnostic reagents and cleaning fluid automation packaging production line, etc.
The characteristics of
1. Painted surface adopts SUS304 stainless steel material, contact material parts adopt SUS316L high quality stainless steel, in line with the GMP requirements;
2. Taken the product design and reasonable structure, stable running, convenient change specifications, 75 decibels or less noise;
3. Taken the production speed is adjustable, squirming packing with high precision, can be in touch screen easy adjustable setting formula;
4. U the whole production line operation chain control, convenient production, also can be stand-alone operation control, more intelligent production.
Technical parameters
| The serial number | Name | parameter |
1 | Applicable specifications | 0.1~1ML |
| 2 | Production capacity | 60 ~ 80 bottles/min |
| 3 | Filling accuracy | ≤±3% |
| 4 | Percent of pass | ≥99.5% |
| 5 | Electrical source | 220V 50Hz |
| 6 | Gas source | 0.5-0.8MPan |
| 7 | Work rate | 5.5kw |
| 8 | Machine net weight | ≈650kg |
| 9 | Overall dimensions | L2200xW1900xH1850mm |
